Measuring range: | 0.75mm~300.0mm(0.03inch~11.8inch) |
Units: | Metric/Imperial unit seletable |
Sound Velocity Range: | 1000m/s~9999m/s(0.039~0.394in/μs |
Display resolution: | 0.01mm or 0.1mm(lower than 100.0mm) 0.1mm(more than 99.99mm) |
Accuracy: | ±(0.5%Thickness+0.04)mm,depends on Materials and conditions |
Data Memory: | 6 files(up to 100 values for each file)of stored values 5 Sound Velocity of stored values |
Power Source: | 2pcs 1.5V AA size,batteries.250 hours typical operating time(LED backlight off) |
Outline Dimensions: | 150mm*74mm*32mm |
Workpiece surface temperature: | - 10 ~ 60 ℃ |
The minimum thickness value capture capacity | With a minimum thickness value capture capacity |
Standard configuration | KT320 host, 5MHz probe, 4 mm steel calibration block, coupling agent, 2 batteries (non - Aviation), Software, RS232 Connect Cabble |
Measurement cycle: | 4 times/SEC, scanning of single point measurement model 20 times per second. |
Weight: | 238 g |
Power source: | Type AA alkaline battery 1.5 V (2) |
Optional attachments: | 2 MHZ, 7 MHZ and 5 MHZ (high temperature) |
