Detection temperature of normal temperature probe | -25 ℃ -200 ℃ |
High temperature probe detection temperature | 200 ℃ -600 ℃ |
Detection range | 1mm ~ 200mm (expandable to 400mm) |
Excitation method | permanent magnet (customizable electromagnetic method) |
Gain | 0-80dB (adjustment accuracy: 0.1dB / 2dB / 6dB) |
Equivalent input noise | <80 × 10-9V/Hz1/2 |
Attenuator accuracy | <± 1dB / 12dB |
Vertical linear error | <3% |
Horizontal linear error | ＜0.2% |
Detection method | positive, negative detection, full detection and radio frequency |
Battery | 7.4V DC, lithium battery, continuous working for 4 hours |
Size | 220mm in length × 125mm in width × 40mm in thickness |
Machine weight | 0.75kg |
